FLAT POLYMERO®

La "megaserie" con una variedad de tipos modélica

Un rayo de luz necesita 1,3 segundos para llegar, desde la tierra, a la luna. ¿Cómo se puede domesticar y dar forma digna a un fenómeno tan poderoso? ¿Cómo se pueden hacer visibles y palpables sus innumerables facetas? Con una serie de luminarias que va más allá de los límites de creación existentes. Una serie que pone en escena los mensajes de manera exigente y eficaz y que no tiene parangón en lo que se refiere a la gran variedad de modelos y variantes.

El sistema FLAT con sus ocho series, múltiples variantes, tamaños y modelos especiales, es una de las más extensas series de luminarias en el mercado. Las opciones del color de la luz y los anillos decorativos, que se pueden pintar en colores RAL, son otras opciones para individualizar las luminarias. Soporte base de la luminaria de pared y techo de metal revestido al polvo. Acoplamiento con el difusor mediante cierre a presión patentado. El modelo con LED destaca por su rendimiento luminoso extraordinario; como detector de movimientos dispone de un sensor de alta frecuencia que prescinde de todos los detectores o interruptores separados.

PUNTOS POSITIVOS FLAT POLYMERO®

    • Una "megaserie" con una variedad de tipos modélica
    • Disponible como luminaria de techo y pared o como luminaria de montaje en suspensión
    • Las variantes con alto tipo de protección permiten el uso en exteriores. En el área interior protege contra el ensuciamiento por moscas o polvo: idóneo en caso de instalaciones de difícil acceso
    • Para el cuerpo de luminaria se disponen, según modelo, de policarbonato de alta calidad o vidrio acrílico (PMMA)
    • Con tecnología LED y también disponible como detector de movimientos con sensor de alta frecuencia integrado
    • Mecanismo de cierre patentado para abrir la(s) luminaria(s) sin herramientas
    • Innumerables posibilidades de individualización
    • Aplicación como techo luminoso listo de instalar, con reducidos costes de montaje y mantenimiento
Flat Polymero IP40, Decken- und Wandleuchte
FLAT POLYMERO

Filter articles

Eliminar filtros

Número de Referencia Dimensiones Duración de servicio nominal Distancia de reconocimiento visual Lámparas potencia del sistema flujo luminoso LED
672479.002.3.07 672479.002.3.07 D 360, H 100 3 h LED 13 W 1.150 lm
672479.002.3.04 672479.002.3.04 D 360, H 100 3 h LED 13 W 1.150 lm
672479.002.3 672479.002.3 D 360, H 100 3 h LED 13 W 1.150 lm
672479.002.1.07 672479.002.1.07 D 360, H 100 3 h LED 13 W 1.100 lm
672479.002.1.04 672479.002.1.04 D 360, H 100 3 h LED 13 W 1.100 lm
672479.002.1 672479.002.1 D 360, H 100 3 h LED 13 W 1.100 lm
672423.002.4 672423.002.4 D 300, H 100 LED 11 W 1.350 lm
672423.002.3 672423.002.3 D 300, H 100 LED 11 W 1.300 lm
672423.002.2 672423.002.2 D 300, H 100 LED 11 W 1.350 lm
672423.002.1 672423.002.1 D 300, H 100 LED 11 W 1.300 lm
672421.002.89 672421.002.89 D 460, H 120 LED 30 W 2.700 lm
672421.002.4.89 672421.002.4.89 D 460, H 120 LED 30 W 2.950 lm
672421.002.4 672421.002.4 D 460, H 120 LED 29 W 2.950 lm
672421.002.2.89 672421.002.2.89 D 460, H 120 LED 30 W 2.800 lm
672421.002.2 672421.002.2 D 460, H 120 LED 29 W 2.800 lm
672421.002.1.89 672421.002.1.89 D 460, H 120 LED 30 W 2.700 lm
672421.002.1 672421.002.1 D 460, H 120 LED 29 W 2.700 lm
672421.002 672421.002 D 460, H 120 LED 29 W 2.700 lm
672401.002.4.07 672401.002.4.07 D 460, H 120 3 h LED + LED 1.3 W 21 W 2.200 lm
672401.002.4.04 672401.002.4.04 D 460, H 120 3 h LED + LED 1.3 W 21 W 2.200 lm
672401.002.4 672401.002.4 D 460, H 120 3 h LED + LED 1.3 W 21 W 2.200 lm
672401.002.2.07 672401.002.2.07 D 460, H 120 3 h LED + LED 1.3 W 21 W 2.100 lm
672401.002.2.04 672401.002.2.04 D 460, H 120 3 h LED + LED 1.3 W 21 W 2.100 lm
672401.002.2 672401.002.2 D 460, H 120 3 h LED + LED 1.3 W 21 W 2.100 lm
672401.002.1.07 672401.002.1.07 D 460, H 120 3 h LED + LED 1.3 W 21 W 1.850 lm
672401.002.1.04 672401.002.1.04 D 460, H 120 3 h LED + LED 1.3 W 21 W 1.850 lm
672401.002.1 672401.002.1 D 460, H 120 3 h LED + LED 1.3 W 20 W 1.850 lm
672401.002.07 672401.002.07 D 460, H 120 3 h LED + LED 1.3 W 21 W 1.800 lm
672401.002.04 672401.002.04 D 460, H 120 3 h LED + LED 1.3 W 21 W 1.800 lm
672401.002 672401.002 D 460, H 120 3 h LED + LED 1.3 W 20 W 1.800 lm
672395.002.89 672395.002.89 D 460, H 120 LED 20 W 1.900 lm
672395.002.4.89 672395.002.4.89 D 460, H 120 LED 20 W 2.050 lm
672395.002.4 672395.002.4 D 460, H 120 LED 19 W 2.050 lm
672395.002.2.89 672395.002.2.89 D 460, H 120 LED 20 W 2.000 lm
672395.002.2 672395.002.2 D 460, H 120 LED 19 W 2.000 lm
672395.002.1.89 672395.002.1.89 D 460, H 120 LED 20 W 2.000 lm
672395.002.1 672395.002.1 D 460, H 120 LED 19 W 2.000 lm
672395.002 672395.002 D 460, H 120 LED 19 W 1.900 lm
672388.002.89 672388.002.89 D 515, H 150 LED + LED 2.2 W 25 W 2.600 lm
672388.002.8.89 672388.002.8.89 D 515, H 150 LED + LED 2.2 W 24 W 2.600 lm
672388.002.8 672388.002.8 D 515, H 150 LED + LED 2.2 W 23 W 2.600 lm
672388.002.6.89 672388.002.6.89 D 515, H 150 LED + LED 2.2 W 24 W 2.750 lm
672388.002.6 672388.002.6 D 515, H 150 LED + LED 2.2 W 23 W 2.750 lm
672388.002.1.89 672388.002.1.89 D 515, H 150 LED + LED 2.2 W 24 W 2.600 lm
672388.002.1 672388.002.1 D 515, H 150 LED + LED 2.2 W 23 W 2.600 lm
672388.002 672388.002 D 515, H 150 LED + LED 2.2 W 24 W 2.600 lm
672386.002.8.07 672386.002.8.07 D 515, H 150 3 h LED 24 W 2.700 lm
672386.002.8.04 672386.002.8.04 D 515, H 150 3 h LED 24 W 2.700 lm
672386.002.8 672386.002.8 D 515, H 150 3 h LED 24 W 2.700 lm
672386.002.6.07 672386.002.6.07 D 515, H 150 3 h LED 24 W 2.850 lm
672386.002.6.04 672386.002.6.04 D 515, H 150 3 h LED 24 W 2.850 lm
672386.002.6 672386.002.6 D 515, H 150 3 h LED 24 W 2.850 lm
672386.002.1.07 672386.002.1.07 D 515, H 150 3 h LED 24 W 2.650 lm
672386.002.1.04 672386.002.1.04 D 515, H 150 3 h LED 24 W 2.650 lm
672386.002.1 672386.002.1 D 515, H 150 3 h LED 24 W 2.650 lm
672386.002.07 672386.002.07 D 515, H 150 3 h LED 24 W 2.550 lm
672386.002.04 672386.002.04 D 515, H 150 3 h LED 24 W 2.550 lm
672386.002 672386.002 D 515, H 150 3 h LED 24 W 2.550 lm
672381.002.3.89 672381.002.3.89 D 360, H 100 LED 20 W 2.150 lm
672381.002.3 672381.002.3 D 360, H 100 LED 19 W 2.150 lm
672381.002.1.89 672381.002.1.89 D 360, H 100 LED 20 W 1.700 lm
672381.002.1 672381.002.1 D 360, H 100 LED 19 W 1.700 lm
672335.002.4.89 672335.002.4.89 D 360, H 100 LED 14 W 1.350 lm
672335.002.4 672335.002.4 D 360, H 100 LED 13 W 1.350 lm
672335.002.3.89 672335.002.3.89 D 360, H 100 LED 14 W 1.200 lm
672335.002.3 672335.002.3 D 360, H 100 LED 13 W 1.200 lm
672335.002.2.89 672335.002.2.89 D 360, H 100 LED 14 W 1.300 lm
672335.002.2 672335.002.2 D 360, H 100 LED 13 W 1.300 lm
672335.002.1.89 672335.002.1.89 D 360, H 100 LED 13 W 1.150 lm
672335.002.1 672335.002.1 D 360, H 100 LED 12 W 1.150 lm
672262.002.89 672262.002.89 D 620, H 160 LED + LED 2.2 W 39 W 4.050 lm
672262.002.8.89 672262.002.8.89 D 620, H 160 LED + LED 2.2 W 39 W 4.250 lm
672262.002.8 672262.002.8 D 620, H 160 LED + LED 2.2 W 38 W 4.250 lm
672262.002.6.89 672262.002.6.89 D 620, H 160 LED + LED 2.2 W 39 W 4.250 lm
672262.002.6 672262.002.6 D 620, H 160 LED + LED 2.2 W 38 W 4.250 lm
672262.002.1.89 672262.002.1.89 D 620, H 160 LED + LED 2.2 W 39 W 4.050 lm
672262.002.1 672262.002.1 D 620, H 160 LED + LED 2.2 W 38 W 4.050 lm
672262.002 672262.002 D 620, H 160 LED + LED 2.2 W 38 W 4.050 lm
672261.002.8.07 672261.002.8.07 D 620, H 160 8 h LED + LED 1 W 37 W 4.200 lm
672261.002.8.04 672261.002.8.04 D 620, H 160 8 h LED + LED 1 W 37 W 4.200 lm
672261.002.8 672261.002.8 D 620, H 160 8 h LED + LED 1 W 37 W 4.200 lm
672261.002.6.07 672261.002.6.07 D 620, H 160 8 h LED + LED 1 W 37 W 4.400 lm
672261.002.6.04 672261.002.6.04 D 620, H 160 8 h LED + LED 1 W 37 W 4.400 lm
672261.002.6 672261.002.6 D 620, H 160 8 h LED + LED 1 W 37 W 4.400 lm
672261.002.1.07 672261.002.1.07 D 620, H 160 8 h LED + LED 1 W 37 W 3.950 lm
672261.002.1.04 672261.002.1.04 D 620, H 160 8 h LED + LED 1 W 37 W 3.950 lm
672261.002.1 672261.002.1 D 620, H 160 8 h LED + LED 1 W 37 W 3.950 lm
672261.002.07 672261.002.07 D 620, H 160 8 h LED + LED 1 W 37 W 3.950 lm
672261.002.04 672261.002.04 D 620, H 160 8 h LED + LED 1 W 37 W 3.950 lm
672261.002 672261.002 D 620, H 160 8 h LED + LED 1 W 37 W 3.950 lm
672260.002.8.07 672260.002.8.07 D 620, H 160 3 h LED + LED 1 W 37 W 4.200 lm
672260.002.8.04 672260.002.8.04 D 620, H 160 3 h LED + LED 1 W 37 W 4.200 lm
672260.002.8 672260.002.8 D 620, H 160 3 h LED + LED 1 W 37 W 4.200 lm
672260.002.6.07 672260.002.6.07 D 620, H 160 3 h LED + LED 1 W 37 W 4.400 lm
672260.002.6.04 672260.002.6.04 D 620, H 160 3 h LED + LED 1 W 37 W 4.400 lm
672260.002.6 672260.002.6 D 620, H 160 3 h LED + LED 1 W 37 W 4.400 lm
672260.002.1.07 672260.002.1.07 D 620, H 160 3 h LED + LED 1 W 37 W 4.050 lm
672260.002.1.04 672260.002.1.04 D 620, H 160 3 h LED + LED 1 W 37 W 4.050 lm
672260.002.1 672260.002.1 D 620, H 160 3 h LED + LED 1 W 37 W 4.050 lm
672260.002.07 672260.002.07 D 620, H 160 3 h LED + LED 1 W 37 W 4.050 lm
672260.002.04 672260.002.04 D 620, H 160 3 h LED + LED 1 W 37 W 4.050 lm
672260.002 672260.002 D 620, H 160 3 h LED + LED 1 W 37 W 4.050 lm
672134.002.7.19 672134.002.7.19 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672134.002.7.1.19 672134.002.7.1.19 D 360, H 116 3 h LED + LED 1.3 W 15 W 1.700 lm
672134.002.5.19 672134.002.5.19 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672134.002.5.1.19 672134.002.5.1.19 D 360, H 116 3 h LED + LED 1.3 W 15 W 1.750 lm
672133.002.8.19 672133.002.8.19 D 460, H 120 8 h LED + LED 1.1 W 21 W 2.100 lm
672133.002.8.07 672133.002.8.07 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.100 lm
672133.002.8.04 672133.002.8.04 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.100 lm
672133.002.8 672133.002.8 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.100 lm
672133.002.7.19 672133.002.7.19 D 460, H 120 8 h LED + LED 1.1 W 22 W 2.100 lm
672133.002.7.07 672133.002.7.07 D 460, H 120 8 h LED + LED 1.1 W 20 W 1.950 lm
672133.002.7.04 672133.002.7.04 D 460, H 120 8 h LED + LED 1.1 W 20 W 1.950 lm
672133.002.7 672133.002.7 D 460, H 120 8 h LED + LED 1.1 W 20 W 1.950 lm
672133.002.6.19 672133.002.6.19 D 460, H 120 8 h LED + LED 1.1 W 21 W 2.200 lm
672133.002.6.07 672133.002.6.07 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.200 lm
672133.002.6.04 672133.002.6.04 D 460, H 120 8 h LED + LED 1.5 W 20 W 2.200 lm
672133.002.6 672133.002.6 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.200 lm
672133.002.5.19 672133.002.5.19 D 460, H 120 8 h LED + LED 1.1 W 22 W 2.100 lm
672133.002.5.07 672133.002.5.07 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.050 lm
672133.002.5.04 672133.002.5.04 D 460, H 120 8 h LED + LED 1.5 W 20 W 2.050 lm
672133.002.5 672133.002.5 D 460, H 120 8 h LED + LED 1.1 W 20 W 2.050 lm
672059.002.8.19 672059.002.8.19 D 460, H 120 3 h LED + LED 1.5 W 21 W 1.950 lm
672059.002.8.07 672059.002.8.07 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.100 lm
672059.002.8.04 672059.002.8.04 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.100 lm
672059.002.8 672059.002.8 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.100 lm
672059.002.7.19 672059.002.7.19 D 460, H 120 3 h LED + LED 1.5 W 21 W 1.950 lm
672059.002.7.07 672059.002.7.07 D 460, H 120 3 h LED + LED 1.5 W 20 W 1.950 lm
672059.002.7.04 672059.002.7.04 D 460, H 120 3 h LED + LED 1.5 W 20 W 1.950 lm
672059.002.7 672059.002.7 D 460, H 120 3 h LED + LED 1.5 W 20 W 1.950 lm
672059.002.6.19 672059.002.6.19 D 460, H 120 3 h LED + LED 1.5 W 21 W 2.250 lm
672059.002.6.07 672059.002.6.07 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.250 lm
672059.002.6.04 672059.002.6.04 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.250 lm
672059.002.6 672059.002.6 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.250 lm
672059.002.5.19 672059.002.5.19 D 460, H 120 3 h LED + LED 1.5 W 21 W 2.100 lm
672059.002.5.07 672059.002.5.07 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.100 lm
672059.002.5.04 672059.002.5.04 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.100 lm
672059.002.5 672059.002.5 D 460, H 120 3 h LED + LED 1.5 W 20 W 2.100 lm
672058.002.7.1.07 672058.002.7.1.07 D 360, H 116 3 h LED + LED 1.5 W 15 W 1.700 lm
672058.002.7.1.04 672058.002.7.1.04 D 360, H 116 3 h LED + LED 1.3 W 15 W 1.700 lm
672058.002.7.1 672058.002.7.1 D 360, H 116 3 h LED + LED 1.3 W 15 W 1.700 lm
672058.002.7.07 672058.002.7.07 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672058.002.7.04 672058.002.7.04 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672058.002.7 672058.002.7 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672058.002.5.1.07 672058.002.5.1.07 D 360, H 116 3 h LED + LED 1.3 W 15 W 1.750 lm
672058.002.5.1.04 672058.002.5.1.04 D 360, H 116 3 h LED + LED 1.3 W 15 W 1.750 lm
672058.002.5.1 672058.002.5.1 D 360, H 116 3 h LED + LED 1.3 W + LED 1.3 W 15 W 1.750 lm
672058.002.5.07 672058.002.5.07 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672058.002.5.04 672058.002.5.04 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672058.002.5 672058.002.5 D 360, H 116 3 h LED + LED 1.5 W 14 W 1.400 lm
672057.002.8.89 672057.002.8.89 D 460, H 120 LED 13 W 1.600 lm
672057.002.8 672057.002.8 D 460, H 120 LED 12 W 1.600 lm
672057.002.7.89 672057.002.7.89 D 460, H 120 LED 20 W 2.100 lm
672057.002.7 672057.002.7 D 460, H 120 LED 19 W 2.100 lm
672057.002.6.89 672057.002.6.89 D 460, H 120 LED 13 W 1.700 lm
672057.002.6 672057.002.6 D 460, H 120 LED 12 W 1.700 lm
672057.002.5.89 672057.002.5.89 D 460, H 120 LED 20 W 2.100 lm
672057.002.5 672057.002.5 D 460, H 120 LED 19 W 2.100 lm
672056.002.8.89 672056.002.8.89 D 360, H 100 LED 15 W 1.650 lm
672056.002.8 672056.002.8 D 360, H 100 LED 14 W 1.650 lm
672056.002.7.89 672056.002.7.89 D 360, H 100 LED 15 W 1.450 lm
672056.002.7 672056.002.7 D 360, H 100 LED 14 W 1.450 lm
672056.002.6.89 672056.002.6.89 D 360, H 100 LED 15 W 1.750 lm
672056.002.6 672056.002.6 D 360, H 100 LED 14 W 1.750 lm
672056.002.5.89 672056.002.5.89 D 360, H 100 LED 15 W 1.450 lm
672056.002.5 672056.002.5 D 360, H 100 LED 14 W 1.450 lm

Quickservice (Articulo disponible de inmediato)

Videos

Imágenes

Aplicationes

Luminarias combinadas para la iluminación de vías de evacuación

Flat Polymero IP40, Decken- und Wandleuchte
FLAT POLYMERO

Luminarias de techo y pared

Flat Polymero IP44
FLAT POLYMERO IP44
Flat Polymero
FLAT POLYMERO
Flat Polymero XXL
Flat Polymero® XXL

Luminarias para montaje en suspensión

Flat Polymero Pendel
Flat Polymero
